Express bag machine

Feedback

Details:

Application

This machine is suitable for heat sealing and cutting bags of BOPP, PP, PE and other materials. Suitable for making flower bags, triangle bags and candy bags. This machine adopts microcomputer fixed length, photoelectric tracking, limit stop, automatic counting, automatic deviation correction, and alarm when the number is reached. The post-feeding adopts double feeding and double-motor double tension control.

Machine features

1.The machine adopt micro-computer control,step motor material-feeding

2.Freely length-fixed,length-fixed photoelectric tracking,photoelectric error correction

3.Unwinding magnetic powder brake control,aotu error correction control

4. Auto meter counting,unwinding up-down;Main unit frequency adjusting speed,exalted shut off

Machine

Product

Machine specification

Bag making width	1200mm
Bag making length	150mm
Bag making speed	80-120 bags/min
Total power	6.5kw
Consumption power	4.5kw
Voltage	220 V, 50 Hz / single Phase
Machine dimension	L : 6000mm , W : 3400mm, H : 2000mm.
Total weight	2200kg

Customer

With 18 years of technology accumulation and thousands of customer application cases, Zhongrui can provide customers with stable and mature coating equipment and is solving the coating problems for customers.
